Cow Dung Log Making Machine

(Eco-Friendly Biomass Log Extruder for Cow Dung, Waste Biomass & Agri Residues)


  • Cow dung is not just a waste — it’s a versatile biomass resource. By converting it into logs (sticks) through mechanical extrusion, we can produce:
    • Eco-friendly fuel logs (as firewood alternative)
    • Logs for cremation use
    • Biodegradable construction material
    • Compostable packaging or vermicompost base
    TECTIKO’s Cow Dung Log Making Machine is a semi-automatic/automatic press system that forms uniform-sized logs from cow dung mixed with agro waste, sawdust or husk, offering a low-cost, high-value output for rural and industrial applications.

    Working Principle:

    • Pre-processed cow dung (semi-dry or mixed) is fed into a hopper.
    • A screw extruder or ram press piston compresses the material into a mould cavity.
    • Uniform pressure forms logs of predefined diameter and length.
    • Logs are air-dried or sun-dried for use as fuel or organic product.

Feature

Specification & Function

Feeding System

Manual hopper or conveyor-fed (optional agitator)

Pressing Mechanism

Screw extruder / Hydraulic piston / Ram-based

Output Shape

Round / Square Logs (2–4 inch dia.)

Cutter

Manual / Auto-length cutter (optional)

Control Panel

Semi-auto / PLC control with safety lockouts

Log Length & Diameter

Customizable based on die/mould used



  • Converts waste cow dung into value-added eco logs
  • No binder required — pure dung or biomass-based
  • Produces logs of uniform size & density
  • Compact footprint — ideal for gaushalas & rural units
  • Available in manual, semi-auto, and PLC versions
  • Suitable for cow dung + agro-waste mixtures (e.g., husk, sawdust)
  • Reduces pollution from open dung disposal or burning
  • Provides additional revenue stream to dairy farms, gaushalas

Component

MOC Options

Frame Structure

Heavy Duty MS / Powder Coated Steel

Screw / Ram

EN8 / Hardened Steel / Alloy Steel

Barrel / Die

SS304 / High-Strength Mild Steel

Motor & Gearbox

Crompton / Siemens / Kirloskar / Bonfiglioli



Parameter

Range / Options

Capacity

100 – 500 kg/hr (customizable)

Log Diameter

50 mm – 100 mm

Motor Power

5 HP – 15 HP

Operation Type

Semi-automatic / Fully Automatic

Feeding Material

Cow dung, sawdust, agro waste (30–35% moisture)

  • Gaushalas & Dairy Farms
  • Rural Enterprises / Panchayat-run units
  • Crematoriums (wood alternative)
  • Biomass Fuel Units
  • Organic Compost Facilities
  • Waste-to-Wealth Social Enterprises
