Compact Flaring System for ETPs

(Space-Saving, Cost-Effective Biogas Flaring Solution for Low-Volume Plants)

In small-scale Effluent Treatment Plants (ETPs) and Sewage Treatment Plants (STPs), anaerobic digesters generate moderate quantities of biogas, which often cannot be utilized fully or continuously.

To safely dispose of surplus or low-pressure biogas, TECTIKO offers a Compact Flaring System specifically designed for ETP applications — ensuring safe, clean, and controlled combustion in a compact, cost-effective format.

Working Principle:

  • Biogas from the digester is directed to the flare stack.
  • An electric spark ignites the gas once minimum pressure is reached.
  • The flame burns off excess methane into harmless CO₂ and H₂O vapor.
  • The system automatically turns on/off based on pressure or manual command.

      Component                                                  Description

  • Type                                           Compact Open Flare (Fixed on Skid or Wall Mount)
  • Ignition                                      Electric Spark Ignition (Automatic / Manual)
  • Control Panel                           Simple On/Off with Safety Lockouts
  • Combustion Chamber            Open Flare Tip with Wind Shield
  • Mounting                                  Ground Skid / Wall Bracket (as per space availability)
  • Stack Height                            2 – 3 meters (customizable)
  • Ideal for small ETP/STP biogas plants
  • Very compact footprint — fits in tight spaces
  • Simple plug-and-play design
  • Low-cost, low-maintenance operation
  • Compatible with low pressure biogas (starting 30–50 mbar)
  • Flameproof ignition system optional
  • Can be upgraded later with UV sensor or auto control

     Component                                           Material Options

  • Flare Tip                                             SS304 / SS316
  • Support Frame                                  Powder-coated MS or SS
  • Valves & Pipe                                    SS304 or Brass (Gas Duty)
  • Enclosure                                          IP55 / IP65 rated box

       Parameter                                       Value / Range

  • Biogas Flow Capacity                 5 – 80 Nm³/hr
  • Ignition Voltage                           220V / 24V Flameproof
  • Stack Height                                2 – 3 meters
  • Pressure Start Range                ~30 mbar
  • Operation Mode                         Manual / Auto Start Option
  • Control Panel                              IP55 On/Off (Optional flame fail)
